| Mechanical Safety Elements |
| Hopper lid protects against entry of foreign objects |
| Hopper grille protects against entry undesiderable objects |
| Electric Safety Elements |
| Auto self- cleaning controlled electrically |
| Electric components protected with grounded |
| Protection against short circuiting on all lines |
| Engines overload protection |
| Low voltage operation and marking: 24V. |
| Activation Elements |
| Stop-locking-run selector |
| Regulation and Signalling Elements |
| Dosage of product (Programming of 1 by 1 Kg/h) |
| Product Density (Programming of 0,01 by 0,01 Kg/l) |
| Signalling electronic circuit testing |
| Signalling of system failure automatic anti-sticking |
| Signalling Engines running |
| Signalling Overload Engines |
| Support Structure Elements |
| Hopper with grille and self- cleaning system. Strong and light |
| Four light legs, with great stability. Facilitate the handling of the machine |
| Two-door lockable electric switchboard |
| Special technical plastic conveyor tube for foodstuffs, length 6 metres |
| Materials and Finishes |
Steel. Anticorrosion treatment. Degreasing, phosphate covering, drying and finally
painting with oven- drying. Colours grey RAL 7035 combined with blue RAL 5012 or
green RAL 6011. A long- lasting resistance is obtained, with the machine always
maintaining a new appearance. |
| Mechanical elements made of technical plastics, special aluminum and stainless steel |
| Certification, Regulation and Guarantee |
Each machine is accompanied by European Certificate (E.C.) manufacturer´s
approval certificate where directives in industrial application guidelines for application
and harmonized regulation for compliance. All of the elements are guaranteed, of the
highest quality, and meet all the legal requirements in force. |
