  Grout Cement Injection Equipment

  Model Tajo 200
   Dimensions and Weight
   Productivity
   Power
   Main Standard Equipment
   Descriptions and Finishes
   Lifting
   The Best Technology
   Catalogue


The grouts with cement doses are from105 to 210 Kg (3 to 6 sacks of 35 Kg).The grouts are carried out through a double mixing system, with an agitator disc of high speed and with an overmovenment turbo.

Water dosage through dosing pump. Digital programming, resolution of 0,1 bar, with visual display and with accurately factor.

IInjection pressure: Adjustable between 0.5 and 16 bar. Digital programming, resolution of 0,1 bar with visual display and with accurately factor and cut pressure.

Hight shear agitator for maintenance with useful capacity of 175 litres, with suitable agitation to facilitate the exit of the air.

Injection carries out through helical pump trade mark DGF, which is specifically designed for the grout pumping. It is impossible to do it easier.

PRODUCTIVITY WATER/CEMENT RELATION
Production (l/h) With additive Without additive
Minimum Maximum
2.000 4.000 36/100 44/100
